ABLEPick pick-to-light communication protocol
45
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 04H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
Data(0)
Buzzer status
Data(1)
Number of beep
The buzzer can be turned “ON” with different period.
Data(0)= 00H buzzer OFF
01H buzzer ON
02H ON with 2 second period
03H ON with 1 second period
04H ON with 0.5 second period
05H ON with 0.25 second period
Data(1)= 01H ~ FFH, can decide the number of beep sound y above period
4.5.1.5 Turn Buzzer OFF
SUB-COMMAND = 05H
This function is the same as 4.3.6
4.5.1.6 Receiving from AT50C/AT70C
The message received from AT50C/AT70C or TCP/IP controller as below:
CCB Description
CCB LEN(L)= 14H
Length of CCB in byte
CCB LEN(H) = 0x00
MESSAGE TYPE = 60H
60H: port1 of controller,
Reserved
Reserved
Reserved
SUB-COMMAND
SUB-NODE
0x01~0xFA (address of AT50C/AT70C)
Data 0
1
st
digit display
Data 1
2
nd
digit display
Data 2
3
rd
digit display
Data 3
4
th
digit display
Data 4
5
th
digit display
Data 5'
6
th
digit display
Data 6
7
th
digit display
………
Data 11'
12
th
digit display
The receiving sub-command, please refer 4.4
4.5.2 Protocol for AT504/AT503A/AT502V
The CCB(communication Control Block ) from Host PC to AT503A/AT502V is as below :
CCB Description
