ABLEPick pick-to-light communication protocol
44
Data 1=’T’
Data 2=’e’
Data 3=’s’
Data 4=’t’
Data 5=’-‘
Data 6'=’1’
Data 7=’2’
Data 8=’3’
Data 9=’4'
Data 10=’5’
Data 11=’6’
Data 12=’7’
4.5.1.1 Turn off message display or clear buffer.
SUB-COMMAND = 01H
Block Length = 8 Bytes
This function is the same as 4.3.2.
4.5.1.2 LED indicator ON
SUB-COMMAND = 02H
CCB LEN (L) = 0AH
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 02H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
Data(0)
Data(1)
LED status
LED indicator can be controlled as “ON” only or blinking with different period.
Data(0)= 00H
Data(1)= 00H Indicator OFF
01H Indicator ON
02H 2 second blinking
03H 1 second blinking
04H 0.5 second blinking
05H 0.25 second blinking
4.5.1.3 LED indicator OFF
SUB-COMMAND = 03H
This function is the same as 4.3.4
4.5.1.4 Turn Buzzer ON
SUB-COMMAND = 04H
CCB LEN (L) = 09H
Data length of this block
CCB LEN (H) = 00H
