ABLEPick pick-to-light communication protocol
25
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 11 H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
This sub-command can force the LED indicator to be blinking. And its flashing time interval
is according to the flash time interval setup of sub-command = 12H.
4.3.9 Configure the flashing time interval
SUB-COMMAND = 12H
CCB LEN (L) = 0AH
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 12 H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
DATA[0] = 00H
Reserved
DATA[1] = Time interval value
00H ~F0H
There are 4 blinking levels
DATA[1] = 00H ~ 01H : the blinking time interval by 0.25 sec
02H ~ 03H : the blinking time interval by 0.5 sec
04H ~ 07H : the blinking time interval by 1 sec
08H ~ F0H : the blinking time interval by 0.25 sec
4.3.10 Showing tag’s node address on display
SUB-COMMAND = 13H
CCB LEN (L) = 08H
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 13 H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
4.3.11 Disable the shortage/down-count button
SUB-COMMAND = 15H
CCB LEN (L) = 08H
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
