ABLEPick pick-to-light communication protocol
27
SUB-COMMAND = 19 H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
Note: The default mode is “pick mode”, tag switches pick mode when it receive the
changing mode command (SUB-COMMAND = 1AH). Additionally, it will return
back to “pick mode” when the tag is reset or power off. However, AT503A, AT502V,
AT506-3W-123, AT50C/AT70C, AT50A-3W-523 do not have stock mode
4.3.16 Switching to picking mode
SUB-COMMAND = 1AH
CCB LEN (L) = 08H
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1A H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
Note: The default mode is “picking mode”, tag switches to stock mode when it receive the
changing mode command (SUB-COMMAND = 19H) and it will return back to
picking mode when the tag is reset or power off.
4.3.17 Disable the confirmation button
SUB-COMMAND = 1BH
CCB LEN (L) = 08H
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1B H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
4.3.18 Enable confirmation button
SUB-COMMAND = 1CH
CCB LEN (L) = 08H
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1C H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
4.3.19 Set available number of digits for up/down counting
Specify the available numbers of digits from the right side on LED display could be
