ABLEPick pick-to-light communication protocol
60
CCB LEN(H) = 0x00
MESSAGE TYPE =60H
Port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 3AH
CONF CMD
SUB-NODE
0x01~0xC8/ 0xFC
40H
1BH
1BH
11H
‘N’
Disable auto mode
4.5.7.5 Write DO Value with mask
CCB
CCB LEN(L) = 0x11
CCB LEN(H) = 0x00
MESSAGE TYPE = 60H
Port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 3DH
SUB-NODE
0x01~0xC8 or 0xFC
Reserved
Low byte data #1
High nibble of mask value
data #2
Low nibble of mask value
data #3
High nibble of DO value
data #4
Low nibble of DO value
High byte data #5
High nibble of mask value
data #6
Low nibble of mask value
data #7
High nibble of DO value
data #8
Low nibble of DO value
Note: The DO bit value is changed when the corresponding
mask bit is '0'
。
Processing method:
A= original DO value
B= DO value specified by AP
M= Mask value specified by AP
Result = ( A and M) or ( B and (not M) )
Example:
data #1 = 0x30('0'), data #2 = 0x30('0')
data #3 = 0x46('F'), data #4 = 0x46('F')
result = 0xFF -> ch0 ~ch7 all 'ON'
data #5 = 0x46('F'), data #6 = 0x46('F')
data #7 = Any value, data #8 = Any value
result = ch8 ~ ch15 no change
