System configuration examples
ATW-R1440 (when using only one unit)
The maximum number of transmitters that can be used is two when the receiver reception mode is set to “Standard”
and four when this mode is set to “HD mode”.
Computer
Switching hub
Power amplifier
ATW-R1440
ATW-T1401/ATW-T1402
ATW-T1406/ATW-T1407
ATW-CHG3Na
ATW-R1440 (when using multiple units)
The maximum number of receivers that can be used is five.
When you are using five receivers, the maximum number of transmitters that can be used is 10 when the receiver
reception mode is set to “Standard” and 20 when this mode is set to “HD mode”.
Computer
Switching hub
Power amplifier
ATW-R1440ATW-T1401/ATW-T1402
ATW-T1406/ATW-T1407
ATW-CHG3Na ATW-CHG3a
