Audio Technica System 20 PRO - Page 88

87
System diagram (ATW-R1440)
CH1
TX GAIN HPF Comp
POST METER
PRE METER
EQ
150Hz Comp4-Band EQ
LEVEL
OFF ONMUTE
-10 to +20dB -20 to +20dB
OFF ON
MIX MIX GAIN
-30 to +10dB
CH2
TX GAIN HPF Comp
POST METER
PRE METER
EQ
150Hz Comp4-Band EQ
LEVEL
OFF ONMUTE
-10 to +20dB -20 to +20dB
OFF ON
MIX MIX GAIN
-30 to +10dB
CH3
TX GAIN HPF Comp
POST METER
PRE METER
EQ
150Hz Comp4-Band EQ
LEVEL
OFF ONMUTE
-10 to +20dB -20 to +20dB
OFF ON
MIX MIX GAIN
-30 to +10dB
CH4
TX GAIN HPF Comp
POST METER
PRE METER
EQ
150Hz Comp4-Band EQ
LEVEL
OFF ONMUTE
-10 to +20dB -20 to +20dB
OFF ON
MIX MIX GAIN
-30 to +10dB
MIXOUT
LIMMITER
MIXOUT
OFF ON
PAD
LINE MIC
30dB
PAD
LINE MIC
30dB
PAD
LINE MIC
30dB
PAD
LINE MIC
30dB
OUTPUT
CH4/MIXOUT
OUTPUT
CH1
OUTPUT
CH2
OUTPUT
CH3
