AUMA ACV 01.2 Operation Instructions

Table 4:
Weights for part-turn actuators SQV 05.2 – SQV 14.2 / SQRV 05.2 – SQRV 14.2
with 3-phase AC motors
Weight
1)
Type designation
Actuator
approx. [kg]
21SQV 05.2/
SQRV 05.2
21SQV 07.2/
SQRV 07.2
26SQV 10.2/
SQRV 10.2
35SQV 12.2/
SQRV 12.2
44SQV 14.2/
SQRV 14.2
Indicated weight includes AUMA NORM part-turn actuator with 3-phase AC motor, electrical con-
nection in standard version, unbored coupling and handwheel. For other output drive types, consider
additional weights.
1)
4.2. Storage
Danger of corrosion due to inappropriate storage!
→
Store in a well-ventilated, dry room.
→
Protect against floor dampness by storage on a shelf or on a wooden pallet.
→
Cover to protect against dust and dirt.
→
Apply suitable corrosion protection agent to uncoated surfaces.
Risk of damage due to excessively low temperatures!
→
Actuator controls may only be stored permanently down to –30 °C.
→
On request, actuators controls may be transported in specific cases and for
short duration at temperatures down to –60 °C.
Long-term storage
For long-term storage (more than 6 months), observe the following points:
1. Prior to storage:
Protect uncoated surfaces, in particular the output drive parts and mounting
surface, with long-term corrosion protection agent.
2. At an interval of approx. 6 months:
Check for corrosion. If first signs of corrosion show, apply new corrosion protec-
tion.
14
SQV 05.2 – SQV 14.2 / SQRV 05.2 – SQRV 14.2 Control unit: electronic (MWG)
Transport und Lagerung ACV 01.2 Non-Intrusive Profibus DP
