AUMA ACV 01.2 Operation Instructions

14. Technical data
Information
The following tables include standard and optional features. For detailed information
on the customer-specific version, refer to the order-related data sheet.The technical
data sheet can be downloaded from the Internet in both German and English at ht-
tp://www.auma.com (please state the order number).
14.1. Technical data Part-turn actuator
Features and functions
Short-time duty S2 - 15 min, classes A and B according to EN 15714-2Type of duty
(Part-turn actuators for open-close
duty)
For 100 % nominal voltage and +40 °C ambient temperature and at load with 35 % of the max. torque.
Intermittent duty S4 - 25 %, class C according to EN 15714-2Type of duty
(Part-turn actuators for modulating
duty)
For 100 % nominal voltage and +40 °C ambient temperature and at modulating torque load.
3-phase AC asynchronous motor, type IM B9 according to IEC 60034-7, IC410 cooling procedure ac-
cording to IEC 60034-6
Motors
Refer to name plate of ACV actuator controls
3-phase AC
Voltages/frequencies
380 – 480220 – 240Volt
50 – 6050 – 60Hz
Wechselstrom
Voltages/frequencies
220 – 240110 – 120Volt
50 – 6050 – 60Hz
Permissible variation of mains voltage: ±10 %
Permissible variation of mains frequency: ±5 %
Mains voltage, mains frequency
Category III according to IEC 60364-4-443Overvoltage category
F, tropicalizedStandard:Insulation class
H, tropicalizedOption:
Thermoswitches (NC)Standard:Motor protection
PTC thermistors (according to DIN 44082)Option:
110 – 120 V AC, 220 – 240 V AC or 380 – 480 V ACVoltages:Motor heater (option)
12.5 WPower
Adjustable between 75° and < 105°Standard:Swing angle
15° to < 45°, 45° bis < 75°, 105° to < 135°, 135° to < 165°, 165° to < 195°, 195° to < 225°Options:
Yes (Part-turn actuators are self-locking if the valve position cannot be changed from standstill while
torque acts upon the output drive.)
Self-locking
Manual drive for setting and emergency operation, handwheel does not rotate during electrical operation.Manual operation
Handwheel lockable
Handwheel stem extension
Power tool for emergency operation with square 30 mm or 50 mm
Option:
Indication whether manual operation is active/not active via single switch (1 change-over contact)Indication for manual operation (op-
tion)
AUMA plug/socket connector with screw-type connectionStandard:Electrical connection
Terminals or crimp-type connection
Gold-plated control plug (sockets and pins)
Option:
Metric threadsStandard:Threads for cable entries
Pg-threads, NPT-threads, G-threadsOption:
Terminal plan according to order number enclosed with deliveryTerminal plan
73
SQV 05.2 – SQV 14.2 / SQRV 05.2 – SQRV 14.2 Control unit: electronic (MWG)
ACV 01.2 Non-Intrusive Profibus DP Technical data
