8.
Select access level via Up ▲ Down ▼, resulting in the following significations:
→
black triangle: ▶ = current setting
→
white triangle: ▷ = selection (not saved yet)
Information: Required access level: Specialist (4) or higher
9.
Press Ok.
➥
Display indicates: Password 0***
10.
Enter password (→ enter password).
➥
Display shows the set address.
11.
Enter new address via Up ▲ Down ▼.
Information: The address range is displayed in round brackets on the screen.
12.
Confirm selection via Save.
➥
The setting for the Profibus address is complete.
10.7. Test run
Only perform test run only once all settings previously described have been
performed.
10.7.1. Direction of rotation at mechanical position indicator: check
Valve damage due to incorrect direction of rotation!
→
If the direction of rotation is wrong, switch off immediately (press STOP).
→
Eliminate cause, i.e. correct phase sequence for cable set wall bracket.
→
Repeat test run.
Information Switch off before reaching the end position.
1. Move actuator manually to intermediate position or to sufficient distance from
end position.
59
SQV 05.2 – SQV 14.2 / SQRV 05.2 – SQRV 14.2 Control unit: electronic (MWG)
ACV 01.2 Non-Intrusive Profibus DP Commissioning (basic settings)
