AUMA ACV 01.2 Operation Instructions

Log on user
7.
Use Up ▲ Down ▼ to select user:
Information: Required user level: Specialist (4) or higher
➥
The symbols have the following meaning:
-
black triangle: ▶ = current setting
-
white triangle: ▷ = selection (not saved yet)
8.
Press Ok .
➥
Display indicates: Password 0***
9.
Enter password (→ enter password).
➥
Display shows the set value.
➥
The bottom row indicates: Edit Esc
10.
Press Edit .
Change value
11.
Enter new value for operating time via Up ▲ Down ▼.
Information: The adjustable operating time range is specified on the actuator
name plate and is indicated on the display in round brackets.
12.
Save new value via Save.
➥
Operating time setting is complete
13.
Return to step 4 (Selection): Press Esc .
10.6. Fieldbus address (slave address): set
Customer settings M0041
Profibus DP M0016
DP1 slave address M0098
DP2 slave address M0295
Default value: 126
Setting range: 0 – 126
Information
Parameter DP2 slave address is only available if redundancy (option) is available.
Select main menu
1. Set selector switch to position 0 (OFF).
2.
Press push button C Setup and hold it down for approx. 3 seconds.
➥
Display goes to main menu and indicates: ▶ Display
Set fieldbus address
3. Select parameter either:
→
(by clicking through the menu)
→
or press and enter IDs M0098 or M0295 (direct selection)
➥
Display indicates: DP1 slave address
4.
Select via Up ▲ Down ▼:
→
▶ DP1 slave address
→
▶ DP2 slave address
➥
The black triangle ▶ indicates the current selection.
5.
Press Ok.
➥
Display shows the set address.
6. The bottom row of the display indicates:
→
Edit→ continue with step 7
→
Up ▲ Down ▼ → continue with step 11
7.
Press Edit.
➥
Display indicates: Observer (1)
58
SQV 05.2 – SQV 14.2 / SQRV 05.2 – SQRV 14.2 Control unit: electronic (MWG)
Commissioning (basic settings) ACV 01.2 Non-Intrusive Profibus DP
