6.3. Accessories for electrical connection
6.3.1. Actuator controls on wall bracket
Design principle Figure 29: Design principle with wall bracket (example)
[1] Wall bracket
[2a] Motor connection/motor control
[2b] Feedback signals from actuator
[3] Plug/socket connector at wall bracket (XM)
[4] Plug/socket connector for actuator (XA)
[5] Electrical connection of actuator controls (XK)
Application
The wall bracket allows separate mounting of actuator controls and actuator.
●
If the actuator cannot be accessed safely.
●
If the actuator is subjected to high temperatures.
●
In case of heavy vibration of the valve.
Information on installa-
tion with wall bracket
●
The permissible cable length between separate local controls and the actuator
amounts to 16 m maximum.
Longer cables require an external filter (available on request)
●
We recommend using an AUMA “LSW” cable set.
32
