AUMA ACV 01.2 Operation Instructions

Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used.
Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary
from actual delivery.
TypeDesignationRef. no.TypeDesignationRef. no.
Sub-assemblyMechanical position indicator553.0Sub-assemblyHousing001.0
Sub-assemblySocket carrier for motor plug/socket con-
nector with cable harness
554.0Sub-assemblyDrive shaft005.0
Sub-assemblyPotentiometer as position transmitter556.0Sub-assemblyMotor coupling005.1
Sub-assemblyPotentiometer without slip clutch556.1Manual drive coupling005.3
Sub-assemblyHeater557.0Sub-assemblyWorm wheel006.0
Sub-assemblyBlinker transmitter including pins at wires
(without impulse disc and insulation plate)
558.0Sub-assemblyManual gearing009.0
Sub-assemblyElectromechanical control unit with
switches, including torque switching heads
559.0–1Torque lever017.0
Sub-assemblyElectronic control unit with magnetic limit
and torque transmitter (MWG)
559.0–2Sub-assemblyGear segment018.0
Sub-assemblySwitch stack for direction OPEN560.0–1Crown wheel019.0
Sub-assemblySwitch stack for direction CLOSE560.0–2Sub-assemblyDrive pinion II for torque switching022.0
Sub-assemblySwitch for limit/torque560.1Sub-assemblyOutput drive wheel for limit switching023.0
Switch case for direction OPEN560.2–1Sub-assemblyDrive wheel for limit switching024.0
Switch case for direction CLOSE560.2–2Sub-assemblyLocking plate025.0
Sub-assemblyRWG position transmitter566.0Sub-assemblyCable for protective earth058.0
Sub-assemblyPotentiometer for RWG without slip clutch566.1Sub-assemblyMotor (incl. ref. no. 079.0)070.0
Sub-assemblyPosition transmitter board for RWG566.2Sub-assemblyPlanetary gearing for motor drive079.0
Sub-assemblyCable set for RWG566.3Sub-assemblyReduction gearing155.0
Sub-assemblySlip clutch for potentiometer567.1Sub-assemblyCover500.0
Sub-assemblyMotor coupling on motor shaft583.0Sub-assemblySocket carrier (complete with sockets)501.0
Sub-assemblyPin for motor coupling583.1Sub-assemblyPin carrier without pins502.0
Retaining spring for motor coupling584.0Sub-assemblySocket for controls503.0
Sub-assemblyOutput drive flange with end stop596.0Socket for motor504.0
Sub-assemblyScrew plug for end stop612.0Sub-assemblyPin for controls505.0
Sub-assemblyEWG position transmitter614.0Sub-assemblyPin for motor506.0
MWG 05.03 cover627.0Sub-assemblyCover for electrical connection507.0
Sub-assemblyPinion shaft629.0Sub-assemblyCoupling525.0
SetSeal kit, smallS1Sub-assemblyScrew plug539.0
SetSeal kit, largeS2Handwheel with ball handle542.0
77
SQV 05.2 – SQV 14.2 / SQRV 05.2 – SQRV 14.2 Control unit: electronic (MWG)
ACV 01.2 Non-Intrusive Profibus DP Spare parts
