Document No.: E4.08.09 E4.08.09 : AE_xx_000
Revision: 13 9 : 00
Page: 39 of 89
Copyright © 2019, Austro Engine GmbH
Dept.: Electric/Electronic
8.2.1 Engine Log File
The engine log file is a convenient way to download and save the basic information relevant
for maintenance organizations and flight departments by clicking on one single button:
ID-Information
Data used to describe a particular installation (engine serial, EECU serial, software and
hardware revisions, etc.) will be downloaded from the EECU.
Operational data
The operational data described in chapter “8.1 Analyzing Operational Data” on page 34, es-
pecially the contents of the “engine statistics” counters, will be downloaded from the EECU.
Fault Code Memory
Each AE300-ECU saves failure information into a non-volatile Fault Code Memory (FCM). This
FCM can hold up to 20 different faults detected, including 9 environmental conditions (e.g.
timestamp, voltages, temperatures, pressures, etc.) which are specific for each possible fail-
ure and are sampled and stored at the time the failure occurred. The full contents of the
FCM will be included in the engine log file download.
Steps:
1) Connect to ECU
2) Select «Engine Logs» tab
3) Click on Save Engine Log button
4) Select file name
5) Press Save button
6) A compressed and encrypted engine log of the name “Engine_Log_YYYYMMDD.ae3”
is available in “My Documents\Austro Engine\AE300-Wizard\HexDump”.
