9.1.2 Reading IQA Codes
This allows to see the IQA codes currently stored and used by the EECU.
Steps:
1) Enter “Qualified Maintenance” mode
2) Select «IQA» tab
3) Click on Read ALL Cylinders button
The IQA codes for a cylinder have to be identical for ECU A and ECU B
If the IQA codes for a cylinder do not agree, the values will be displayed in RED
