8.3.4.2 Live View – Importing Live View Recordings

Live View recordings saved during previous sessions can be analyzed offline using the

AE300-Wizard without a CAN adapter, by a maintenance technician at the office or by an

Austro Engine expert in case of escalated situations.

Steps:

1) Enter “offline” mode by running the AE300-Wizard without CAN adapter

2) Go to «Live View» tab

3) Press Load Live View Recording button

4) Select new (“Wizard files” = default) or

old (“Xml files”) format of life view recording

5) Select file name (e.g. LifeView_YYYYMMDD.ae3 or LifeView_YYYYMMDD.xml)

6) Press the Open button

7) The “Live View” windows pops up

8) Analyze the recording as explained in section “8.3.4.3 Live View – Analyzing Live View

Recordings”
