Moving the Cabinet to the Site
There are two ways to move the cabinet to the installation site:
Hoist
Forklift
WARNING
Follow the safety instructions that apply to the hoisting equipment or forklift to move
the cabinet.
Take into account the dimensions, mass, and center of gravity of the MaxiCharger.
CAUTION
DO NOT drop the cabinet or subject it to strong impact.
DO NOT exceed a tilting angle of 30°.
Avoid excessive force on the hoisting points.
Hoisting the Cabinet
To hoist the cabinet
Install the four eyebolts (M16) to the lifting holes (A).
Connect the cables of the hoisting equipment to the eyebolts or bolts with lifting
loops.
Move the cabinet to the construction site.
Figure 4-2 Hoisting the Cabinet
