Autel MaxiCharger DC Fast - Packaging Specifications

68
Packaging Specifications
Table 9-3 General Dimensions
Parameter
Specification
MaxiCharger DC 120 MaxiCharger DC 240
Width of the Cabinet
820 mm 32.28 in 820 mm 32.28 in
Depth of the Cabinet
600 mm 23.62 in 700 mm 27.56 in
Height of the Cabinet
1950 mm 76.77 in 1950 mm 76.77 in
Length of the charging
cable (air-cooled)
4000 mm (157.48 in)
(Optional) 7500 mm (295.28 in)
Table 9-4 Packaged Product Specifications
Parameter Specification
Width
1240 mm 48.82 in
Depth
1000 mm 39.37 in
Height
2146 mm 84.49 in
Mass of the Package
55 kg 121 lb.
Maximum Tipping Angle
30°
NOTE: The MaxiCharger is mounted on a standard size wooden pallet and
protected to prevent damages during transport.
