AC Input and DC Output Specifications
Table 9-12 AC Input Wire Specifications
Parameter Specification
Wire Shielding (optional)
If the local regulations require shielded
wires, connect the wire shielding to the
PE bus at both ends of the wire.
Diameter of the Phase Conductors
Refer to the local regulations.
Diameter of the PE Conductor
Refer to the local regulations
Surface and Diameter
Based on the current rating of the
MaxiCharger and local regulations.
Material
Copper
Maximum Temperature of the Input
Wires
75°C (167°F)
Table 9-13 Detail AC Input Specifications
Type
Parameter
MaxiCharger DC
40 60 80 100 120 160 180 200 220 240
Maximum
Rated Input
Current (A)
62 93 124 155 186 248 280 310 341 372
Recommended
Input Circuit
Breaker (A)
100 125 160 200 250 320 400 400 500 500
Maximum
Power
Dissipation
(kVA)
43 64 86 107 129 172 193 215 236 258
Short Circuit
Current Rating
(kA)
35 35 35 35 35 35 35 35 35 35
Maximum Size
of the Input
Wire (mm2)
120 120 120 120 120 120 120 120 120 120
