32
Installing the Cabinet
To install the cabinet
Remove the front and rear base covers (A) using a screwdriver.
Open the front door of the cabinet. Remove the M6 screws (C) and the
insulating barrier (B) from the cabinet. (Reinstall the insulating barrier when the
commissioning procedure is complete.)
Figure 5-5 Removing the Base Covers
Figure 5-6 Removing the Insulating Barrier
