Autel MaxiCharger DC Fast - Technical Specifications; General Specifications

66
Technical Specifications
General Specifications
Table 9-1 Product Specifications
Parameter Description
Compliance and Safety
 IEC 61851-1
 IEC 61851-23
 IEC 61851-21-2
 IEC 61000
IP Rating
IP54
IK Rating IK10
Short Circuit Current Rating
35 kA
EMC
 Class A
 Class B optional
Output Voltage
 CCS: 150 to 1000 V DC
 CHAdeMO: 150 to 500 V DC
Output Current (for MaxiCharger DC
120)
 CCS: 200 A
 CHAdeMO: 125 A/200 A
Output Current (for MaxiCharger DC
240)
 CCS: 200 A
 CCS boost: 300 A (peak 400 A)
 CHAdeMO: 125 A/200 A
EV Charging Cable Length
 4 m (157.48")
 7.5 m (295.28")
Certification
 CE
 UKCA
 TR25
Maximum noise level at a distance of
1 m
< 65 dB @ 1m /25℃/full load
