seal it using duct seal.
If needed, connect two AC input wires of the same type to each connector as shown
below:
Figure 5-15 Connecting the Two AC Input Wires
Connecting the Ethernet Cable
Connect the Ethernet cable to one of the RJ45 ports.
Figure 5-16 Connecting the Ethernet Cable
