27
Preparing the Foundation
To prepare a casted foundation
Dig a hole based on the foundation size.
IMPORTANT
The minimum sizes of the hole for MaxiCharger DC 120 and MaxiCharger DC 240
are 820 x 640 x 500 mm and 820 x 740 x 500 mm, respectively.
The foundation must meet the C30 requirements.
Figure 5-2 Digging a Hole
