Installing the External Residual-current Device
The MaxiCharger includes a Type A RCD integrated in the main breaker, and a RCCB
for the auxiliary path.
The use of external RCD may cause a nuisance tripping during transient conditions such
as when the AC contactor turns on at the start of charging. If an external residual-current
device cannot be avoided due to local regulations, the in-rush current should be
considered when selecting the device.
For the specifications of the residual-current device and the incidental current peaks,
refer to Technical Specifications.
Preparing for Commissioning
IMPORTANT
Only a manufacturer qualified service engineer can commission the MaxiCharger.
To perform the commissioning
Ensure the site complies with the following requirements:
The MaxiCharger is installed according to the instructions in this manual.
AC input power is available.
Internet access is available through a wired Ethernet connection, cellular
service, or Wi-Fi.
An EV of each type of connector must be available for a compatible test
during commissioning.
The site operator or owner is available to receive instructions from the
manufacturer certified service engineer when the MaxiCharger is
installed.
Ensure the following information is collected:
Name and address of the site
Contact information of the on-site contact person
Specification of the external fuse or breaker at the power distribution
panel
Date when the installation is done
Photo of the MaxiCharger and the site surroundings
Special remarks (if any)
Someone should be present for assistance to energize the power to the
MaxiCharger on the distribution panel.
IMPORTANT
The conduit opening must be sealed to protect the wiring from the environment.
