43
IMPORTANT
Install the sealing boards into the slots where the charging modules are not inserted.
Tightening the screws to the torque of 1.2 N·m (10.6 lb·in) to secure the
modules.
After the installation is complete, set the hardware address. For details, contact
manufacturer certified installation engineer.
Seal the cable holes of the cabinet and close the doors.
Figure 5-20 Sealing Board
Figure 5-21
