Installation Tools
Table 4-2 Installation Tools
Tool Specification
Philips Screwdriver
Size: PH2
Slot Screwdriver
Size: 2.5 and 4.5
Open Spanner
 M8 (13 mm)
 M10 (15 mm)
 M16 (24 mm)
Ratchet Spanner with
Socket and Extension
 M8 (13 mm)
 M10 (15 mm)
 M16 (24 mm)
Voltage Tester
Standard
Digital Multimeter
Standard
Hoisting Equipment or
Forklift
Capable to lift the MaxiCharger safely. Refer
to different specifications in Technical
Specifications.
Wire Stripper Tool
To strip the wires of the AC input cable.
Cable Lug Tools
Size: M10 (AC wires)
NOTE
 The tools mentioned above are not provided. Be sure to have all the tools prepared
prior to the installation.
 This tool list does not necessarily include all the tools you may need.
