Autel MaxiCharger DC Fast - Page 37

31
Table 5-6 Drilling Holes Specifications
Parameter
Specification
MaxiCharger DC 120 MaxiCharger DC 240
X
820 mm 32.28 in 820 mm 32.28 in
X1
95 mm 3.74 in 95 mm 3.74 in
X2
630 mm 24.80 in 630 mm 24.80 in
X3
132 mm 5.51 in 140 mm 5.51 in
X4
220 mm 8.66 in 220 mm 8.66 in
Y
640 mm 25.20 in 740 mm 29.13 in
Y1
94.3 mm 3.71 in 144.3 mm 5.68 in
Y2
450 mm 17.72 in 450 mm 17.72 in
Y3
131 mm 5.16 in 91.5 mm 3.60 in
Y4
120 mm 4.72 in 120 mm 4.72 in
Tap four expansion bolts (M16 x 150) in the drilled positions (D) on the
foundation. The expansion bolts needs to be 60 mm above the foundation.
