74
Type
Parameter
MaxiCharger DC
40 60 80 100 120 160 180 200 220 240
(XLPE
suggested)
Table 9-14 General DC Output Specifications
Parameter Specification
DC Output Voltage Range, CCS
150 to 1000 V DC
DC Output Voltage Range, CHAdeMO
150 to 500 V DC
Minimum DC Output Current
5 A
Connection Standard
 CCS: IEC 61851-1:2017, IEC
61851-23:2014, IEC 62196-1:2014,
IEC 62196-3:2014
 CHAdeMO: CHAdeMO 1.2
Table 9-15 Detail DC Output Specifications
Parameter
MaxiCharger
DC Output
Power on
One EV
Charging
Cable (kW)
DC Output
Power Two EV
Charging Cables
(kW)
S
imultan
-eous
DC on
Two
Outlets
Maximum DC
Output Current
40
Max.40 kW Max. 20 kW x 2
Yes
 CCS
connector:
200 A
 CHAdeMO
connector:
125 A/200 A
60
Max.60 kW Max. 40 + 20 kW
80
Max.80 kW Max. 40 kW x 2
100
Max.100 kW Max. 60 + 40 kW
120
Max.120 kW Max. 60 kW x 2
160
Max.160 kW Max. 80 kW x 2
 CCS
connector:
200 A
180 Max.180 kW
Max. 100 kW +
80 kW
200 Max.200 kW Max. 100 kW x 2
