Table 5-1 Location Requirements (for MaxiCharger DC 120)
Parameter
Specification
mm in
X1
820 32.28
X2
800 31.5
X3
800 31.5
Y1
600 23.62
Y2
500 19.69
Y3
850 33.46
Table 5-2 Location Requirements (for MaxiCharger DC 240)
Parameter
Specification
mm in
X1
820 32.28
X2
900 35.43
X3
900 35.43
Y1
700 27.56
Y2
500 19.69
Y3
850 33.46
Choose a site where the charging cable is of sufficient length to be connected to
the EV charge port. The standard length of the charging cable is 4 meters, but a
7.5-meter cable is also available.
Take into account the limited reach of a wheelchair user.
Determine appropriate ground anchoring locations where concrete exists or can be
installed (no asphalt surfaces).
Consider locations where it will be easy to add future stations.
