Wiring Diagrams
© Copyright Re
ser
ved A
utonic
s Co., Ltd.
33
4.5.2
Communica
tion Line W
iring
Do not tie together with the
AC power lin
e.
Only use twisted pair wires for
the communication lines.
Do not allow the communication line to exceed 800m in length.
For further details, please refer t
o
6.6
Communication Settings
.
32
