2 Specifications
© Copyright Reserved Autonics Co., Ltd. 21
2 Specifications
2.1 Ratings
Series
TK4
TK4S TK4SP TK4M TK4W TK4H TK4L
Power Supply 100-240 VAC, 50/60 Hz
Allowable voltage range ±10% of rated voltage
Power Consumption Max. 8 VA
Display 7-Segment (red), all other displays (green, amber, red LED)
Character
Size
PV(W x H)
7.0X14.0mm 7.0X14.0mm 9.5X20.0mm 8.5X17.0mm 7.0X14.6mm 11.0X22.0mm
SV(W x H)
5.0X10.0mm 5.0X10.0mm 7.5X15.0mm 6.0X12.0mm 6.0X12.0mm 7.0X14.0mm
Input
Types
RTD
JPT 100 Ω, DPT 100 Ω, DPT 50 Ω, CU 100 Ω, CU 50 Ω, and Nikel 120 Ω
(6 types)
Thermocouples K, J, E, T, L, N, U, R, S, B, C, G, and PLII (13 types)
Analog
Voltage: 0 to 100mV, 0 to 5V, 1 to 5V, and 0 to 10 V (4 types)
Current: 0 to 20mA and 4 to 20mA (2 types)
Display
Accuracy
RTD
※
1
At room temperature (23℃ ± 5℃): PV ± 0.3% or ± 1℃ (whichever is greater) ± 1 digit.
At all other temperature ranges: PV ± 0.5% or ± 2℃ (whichever is greater) ± 1 digit.
In case of TK4SP series, ±1℃ will be added.
Thermocouples
Analog
At room temperature (23℃ ± 5℃): ± 0.3% F. S . ± 1 digit.
At all other temperature ranges: ± 0.5% F.S . ± 1 digit.
C. T. Input ± 5% F. S . ± 1 digit
Control
Output
Relay 250 VAC 3A 1a
SSR 11 VDC ± 2 V 20 mA Max.
Current Choose between DC0 to 20 mA and DC4 to 20 mA (Load 500 Ω Max.)
Alarm Output 250 VAC 3A 1a 2Contacts(TK4SP-1contact)
Output
Option
Transmission
Output
DC4 to 20mA (Load 500 Ω Max. Output Accuracy: ±0.3% F.S)
Communication RS485 Communication Output (Modbus RTU)
Input
Option
C. T.
0.0 to 50.0A (primary heater current reading range) ※1000:1 C. T. Ratio
Digital Input
Contact - On: < 2kΩ, Off: > 90kΩ
Non-Contact - On: < 1.0 V Residual Voltage, Off: < 0.1mA Leakage Current
※TK4S/M-1ea(due to limited terminal), TK4H/W/L-2ea(except TK4SP)
Control
Type
Heating and
Cooling
On/Off, P, PI, PD, and PID Control
Heating or
Cooling
