1 Product Introduction
© Copyright Reserved Autonics Co., Ltd. 17
1.3 Model Lineup
TK 4 S - 1 4 R R
※1: In case of SP series, option control output selection and digital input will be limited
due to number of terminals.
※2: “S” represents SSRP drive voltage output support model which SSR standard/cycle/
phase control are available. “C” represents both current and SSR(standard) output
support model.
※3:. Select “R” or “C” type in case of using heating & cooling control. “N” type in case fo
using standard control.
Category Description
① Item
TK Temperature/Process controller
② Digit
4 9999(4Digit type)
③ Size
SP
48 mm(W) X 48 mm(H) (Plug Type
※
4
)
S 48 mm(W) X 48 mm(H) (Terminal Block Type)
M 72 mm(W) X 72 mm(H)
W 96 mm(W) X 48 mm(H)
H 48 mm(W) X 96 mm(H)
L 96 mm(W) X 96 mm(H)
④ Output Option
※
1
SP 1 ALARM1 output
S
M
W
H
L
1 ALARM1 output
2 ALARM1 + ALARM2 output
R ALARM1 + Transmission output
T ALARM1 + RS485 Comm. output
A ALARM1 + ALARM2 + Transmission output
B ALARM1+ALARM2+RS485 Comm. output
⑤ Power Supply
4 100 to 240VAC, 50/60Hz
⑥ OUT1 Control Output
※
2
R Relay output
S SSRP Output
C Current output + SSR drive output
⑦ OUT2 Control Output
※
3
Standard N
None ※Select in case of standard control
(heating or cooling)
Heating,
Cooling
R Relay output
C Current output + SSR drive output
To Next Page
