6.2.4.3 Initial MV for Manual Control [PAR5 → PR.MV]
If the baseline MV for manual control is configured to PR.MV (Preset Manual MV), you can
set the initial MV for manual control.
Setting
Group
Parameter Setting Range
Factory
Default
Unit
PAR5
PR.MV
Standard
Control
ON/OFF
Control
000.0
(OFF)/
100.0
(ON)
000.0
%
PID
Control
000.0
to
100.0
Heating
and
Cooling
Control
ON/OFF
Control
-100.0
(Cooling
On)
/
000.0
(OFF)/
100.0
(Heating ON)
PID
Control
-100.0
(Cooling) to
000.0
(OFF)
to
100.0
(Heating)
When in heating and cooling control mode, a setting between
0.1
and
100.0
will be applied as heating MV and a setting between
0.1
and
-
100.0
will be applied as cooling MV.
6.2.5 Output Settings
6.2.5.1 Control Output (OUT1/OUT2) Selection [PAR3 → OUT1/OUT2]
 In case of selecting the Models with current control output, both current and SSR
outputs are available. You can therefore choose the right output type depending on
application environments.
 OUT1: Selects OUT1 control output.
 OUT2: Selects OUT2 control output.
Setting Group Parameter Setting Range
Factory
Default
Unit
PAR3
OUT1
SSR
/
CURR
SSR
-
OUT2
