Autonics TK4L User Manual

6 Parameter Settings and Functions
© Copyright Reserved Autonics Co., Ltd. 97
6.7 Additional Features
6.7.1 Monitoring
Refer to 5-3-4. MV Monitoring and Manual Control Settings.
6.7.1.1 Control Output MV Monitoring
Monitors and displays the current control output MV.
6.7.1.1.1. Heating MV Monitoring
 Displays the current heating MV during heating control or heating and cooling control.
 Users may manually adjust the MV to control the temperature.
 Measurement Range: H 0.0 to H100 (Unit: %)
Capable of displaying MV with a moving decimal point (
H99.9
→
H100
).
6.7.1.1.2. Cooling MV Monitoring
 Displays the current cooling MV during cooling control or heating and cooling control.
 Users may manually adjust the MV to control the temperature.
 Measurement Range: C 00 to C100 (Unit: %)
Capable of displaying MV with a moving decimal point (
C99.9
→
C100
).
6.7.1.2 Heater Current Monitoring [PAR1 → CT-A]
A feature that monitors and displays the current of a heater (load) being controlled by
control output.
Setting
Group
Parameter Measurement Range Unit
PAR1
CT-A
0.0
to
50.0
A
A current transformer is used to measure and display the heater's (load)
current.
