Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 37
5.2.5 Connect to Disable Input Device
This menu allows you to connect a detection zone to a Disable Input
Device (DID).
From the Detection Zones Menu (5.2.1), perform the following:
After pressing the Function button for the selected detection
zone(s), use the arrow down button to select Connect to Disable
Input Device, then press Enter twice.
Use the arrow button to select the Disable Input Device, then
press Enter.
To confirm the setting, press Enter once more.
5.2.6 Connect to Local Alarm Delay Unit
This menu allows you to connect a detection zone to a Local Alarm
Delay Unit.
From the Detection Zones Menu (5.2.1), perform the following:
After pressing the Function button for the selected detection
zone(s), use the arrow down button to select Connect to Local
Alarm Delay Unit, then press Enter twice.
Use the arrow button to select the Local Alarm Delay Unit, then
press Enter.
To confirm the setting, press Enter once more.
5.2.7 Connect to Panel
This menu allows you to connect a detection zone to a “Larmlagring”
Panel. Note that the menu selection is available only if a such panel
is connected to the system.
From the Detection Zones Menu (5.2.1), perform the following:
After pressing the Function button for the selected detection
zone(s), use the arrow down button to select Connect to Panel,
then press Enter twice.
Use the arrow button to select the Panel, then press Enter.
To confirm the setting, press Enter once more.
