Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 58
5.6.7 Show Activating Detection Zones
This menu allows you to view all detection zones that are connected
to the selected loop output.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Loop Outputs Menu (5.6.1), perform the following:
 After pressing the Function button for the selected Loop
Output(s), use the arrow down button to scroll downwards to
Show Activating Detection Zones, then press Enter.
In the display you will now see a list of all detection zones that are
connected to the selected loop output.
5.6.8 Show Activating Points
This menu allows you to view all points that are connected to the
selected loop output.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Loop Outputs Menu (5.6.1), perform the following:
 After pressing the Function button for the selected Loop
Output(s), use the arrow down button to scroll downwards to
Show Activating Points, then press Enter.
In the display you will now see a list of all points that are connected
to the selected loop output.


