Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 68
5.7.13 Show Connected Units
This menu allows you to view all connections that are connected to
the selected local output. The menu selection applies to onboard
General Outputs only.
Note that the menu selection does not apply to Fire Alarm Routing
Equipment (FARE) and Fire Warning Routing Equipment (FWRE).
From the Local Outputs Menu (5.7.1), perform the following:
 After pressing the Function button for the selected Local
Output(s), use the arrow down button to scroll downwards to
Show Connections, then press Enter.
In the display you will now see a list of all connections that are
connected to the selected local output.
 Use the arrow up/down button to select a connection, then press
Enter.
In the display you will now see the name and unit function.

