Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 87
5.12.6 Show Connected Units
This menu allows you to view all outputs (or units that will be
activated by the group) that are connected to the selected Activation
Group.
From the Activation Groups Menu (5.12.1), perform the
following:
After pressing the Function button for the selected activation
group(s), use the arrow down button to scroll downwards to
Show Connections, then press Enter.
In the display you will now see a list of all connections that are
connected to the selected Activation Group.
Use the arrow up/down button to select a connection, then press
Enter.
In the display you will now see the name and unit function.
5.13 External Interfaces
5.13.1 Accessing the menu
From the Service Menu, perform the following:
Use the arrow down button to scroll downwards to
Unit Configuration, then press Enter.
Use the arrow down button to select External Interfaces, then
press Enter once more.
A list of all related interfaces will appear in the display, including:
o Serial Port Settings (chapter 5.13.2)
o TCP/IP Port Settings (chapter 5.13.3)
o ESPA (chapter 5.13.4)
o MODBUS (5.13.5)
o VDR (chapter 5.13.6)
o Remote Access (chapter 5.13.7)
Use the arrow up/down buttons to select the External Interface
that is to be configured, then follow the instructions in the
relevant chapter.
