5.4 Points
5.4.1 Accessing the Menu
From the Service Menu, perform the following:
Use the arrow down button to scroll downwards to
Unit Configuration, then press Enter.
Use the arrow down button to select Points, then press Enter
once more.
Use the arrow up/down buttons to select the point that
is to be configured.
To view or change properties for the selected point, refer to
Configure Properties for a Point (chapter 5.4.2).
To access available functions for a selected point, press the
Function button
, or use, if necessary, the multiselect feature
to select several points by pressing the Select button to mark
the points that are to be configured, and then press the Function
button
.
The following menu selections will appear:
o Move to Detection Zone (/Create New) (chapter 5.4.3)
o Connect to Output (chapter 5.4.4)
o Connect to Activation Group (/Create New) (chapter 5.4.5)
o Disconnect from Output (chapter 5.4.6)
o Disconnect from Activation Group (chapter 5.4.7)
o Show Connected Units (chapter 5.4.8)
Scroll with the arrow up/down buttons to select the desired menu,
then follow the instructions in the relevant chapter.
