Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 64
5.7.5 Disconnect from Output
This menu allows you to disconnect a selected local output from an
existing output. The menu selection applies to onboard General
Outputs only.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Local Outputs Menu (5.7.1), perform the following:
After pressing the Function button for the selected Local
Output(s), use the arrow down button to scroll downwards to
Disconnect from Output, then press Enter.
In the display you will now see a list of all outputs that are connected
to the selected local output.
To disconnect the selected local output from an output, use the
arrow down button to select the output, then press
Enter.
To confirm the setting, press Enter once more.
5.7.6 Disconnect from Activation Group
This menu allows you to disconnect a selected local output from an
existing Activation Group (refer to chapter 5.12). The menu selection
applies to onboard General Outputs only.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Local Outputs Menu (5.7.1), perform the following:
After pressing the Function button for the selected Local
Output(s), use the arrow down button to scroll downwards to
Disconnect from Activation Group, then press Enter.
In the display you will now see a list of all Activation Groups
that are connected to the selected local output.
To disconnect the selected local output from an Activation Group,
use the arrow down button to select the activation group, then
press Enter.
To confirm the setting, press Enter once more.
