Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 59
5.6.9 Show Activating Inputs
This menu allows you to view all inputs that are connected to the
selected loop output.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Loop Outputs Menu (5.6.1), perform the following:
After pressing the Function button for the selected Loop
Output(s), use the arrow down button to scroll downwards to
Show Activating Inputs, then press Enter.
In the display you will now see a list of all inputs that are connected
to the selected loop output.
5.6.10 Show Activating Groups
This menu allows you to view all activating groups (groups; meaning
“Activation Groups”) the selected loop output is connected to.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Loop Outputs Menu (5.6.1), perform the following:
After pressing the Function button for the selected Loop
Output(s), use the arrow down button to scroll downwards to
Show Activating Groups, then press Enter.
In the display you will now see a list of all activation groups that are
connected to the selected loop output.
