Warning:
The AT&T Switched Network Protocol prohibits restricted displays of connected numbers.
Display problems occur if you administer the 1a country-protocol/ protocol-version
combination on the DS1 screen and administer the ISDN-PRI Trunk Group to restrict
sending the connected number.
DCP/ANALOG Bearer Capability
Sets the information transfer capability in a bearer capability IE of a setup message to speech
or 3.1kHz. Available only with the ISDN-PRI Signaling Mode.
Valid Entry Usage
3.1kHz Provides 3.1 kHz audio encoding in the information transfer capability.
speech Provides speech encoding in the information transfer capability.
Interface
Controls how the server negotiates glare with the far-end switch. The servers at either end of
the DS1 link must have complementary settings in this field. Otherwise, the D-channel cannot
function. For example, if the Avaya S8XXX server at one end of the link is administered as
network, the other end must be administered as user. Available only when this DS1 link is
providing an ISDN-PRI connection in a private network.
Private network applications in the U.S.
Valid Entry Usage
network The server overrides the other end when glare occurs, and when
connecting the server to a host computer.
user The server releases the contested circuit and looks for another when
glare occurs, and when connecting the server to a public network.
Private network applications outside the U.S.
Valid Entry Usage
peer-master The switch overrides the other end when glare occurs.
peer-slave The switch releases the contested circuit and looks for another when
glare occurs.
ITN-C7 Long Timers
Controls the T302 and T303 timers.
Available only if the Signaling Mode is isdn-pri.
Standard Local Survivability (SLS)
152 Administering Avaya G430 Branch Gateway October 2013
