Root level
command
Command Description
set system
location
Set the location information for
this Branch Gateway system
set system
name
Set the name of the Branch
Gateway system
show pmi Display the current Primary
Management Interfaces
Example of defining a default gateway
The Branch Gateway uses a default gateway to connect to outside networks that are not listed
on the Branch Gateway’s routing table. To define a default gateway, use the ip default-
gateway command, followed by either the IP address or name (type and number) of the
interface you want to define as the default gateway.
Example
The following example defines the interface with the IP address 132.55.4.45 as the default
gateway:
ip default-gateway 132.55.4.45
Example
To define a default gateway with IPv6 address 2001:db8:2179::2
Gxxx-001(super)# ipv6 default-gateway 2001:db8:2179::2
Branch Gateway Controller configuration
The Branch Gateway Controller (MGC) controls telephone services on the Branch Gateway.
You can use a server with Avaya Aura
®
Communication Manager software as an MGC. The
Branch Gateway supports both External Call Controllers (ECC) and Internal Call Controllers
(ICC). An ICC is an Avaya S8300 Server that you install in the Branch Gateway as a media
module. An ECC is an external server that communicates with the Branch Gateway over the
network.
When the Branch Gateway uses an ECC, it can use a local S8300 as a backup controller for
Enhanced Local Survivability (ELS). The S8300 functions in Survivable Remote Server (SRS)
mode. If the ECC stops serving the Branch Gateway, the S8300 takes over the service.
Related topics:
Locating the Branch Gateway serial number on page 68
Basic device configuration
Administering Avaya G430 Branch Gateway October 2013 67
