RTP statistics summary reports output field descriptions
Field Description
Total QoS traps The total number of QoS traps sent since the
RTP statistics application was enabled or
since the last use of the rtp-stat
clear command
QoS traps Drop The number of QoS traps dropped by the rate
limiter since the RTP statistics application
was enabled or since the last use of the
rtp-stat clear command
Qos Fault/QoS Clear General QoS state: QoS Fault means that
the number of active RTP sessions with QoS
faults is currently higher than the QoS fault
boundary. QoS Clear means that the number
of active RTP sessions with QoS faults is
currently less than or equal to the QoS clear
boundary. You can configure the QoS fault
and clear boundaries using the rtp-stat
fault command. See
QoS fault and clear
traps on page 357.
Engine ID The ID of the VoIP engine. Since the Branch
Gateway has one VoIP engine, one line
appears in the table.
Description Description of the VoIP engine
Uptime The uptime of the RTP statistics application.
This is the time since the RTP statistics
application was enabled or since the last use
of the rtp-stat clear command.
Active Session The number of active sessions / number of
active sessions with QoS problems
Total Session The total number of sessions / number of
sessions that had QoS problems
Mean Duration The mean RTP session duration (calculated
only for terminated calls)
Tx TTL The IP Time To Live (TTL) field for
transmitted RTP packets
Viewing RTP session statistics
About this task
Using the CLI, you can view a summary of active and terminated sessions and you can view
RTP statistics for a given RTP session.
Monitoring applications
Administering Avaya G430 Branch Gateway October 2013 359
