source-ip <Branch voice Subnet> <Branch voice Subnet Mask>
destination-ip any
composite-operation Permit
exit
ip-rule default
composite-operation deny
exit
exit
interface vlan 1
description “VoIP_VLAN”
ip address <branch voice subnet IP address> <branch voice subnet mask>
icc-vlan
pmi
exit
interface vlan 2
description “DATA_VLAN”
ip address <branch data subnet IP address> <branch data subnet mask>
exit
interface vlan 3 description “External_router_connection” ip address
<external router IP address> <external router subnet mask> exit
interface fastethernet 10/3
encapsulation pppoe
traffic-shape rate 256000
ip address <Branch Office Internet public Static IP Address> <Branch
Office Internet
public net mask>
ip crypto-group 901
ip access-group 301 in
ip access-group 302 out
exit
ip next-hop-list 1 next-hop-ip 1 <external layer 3 router IP address>
exit
ip next-hop-list 2
next-hop-interface 1 FastEthernet 10/3 next-hop-ip 2 <external layer 3 router
IP address>
exit
ip pbr-list 801
ip-rule 10
!
! The following command specifies the Voice bearer
!
dscp 46
next-hop list 1
exit
ip-rule 20
!
! The following command specifies the Voice Control
!
dscp 34
next-hop list 2
exit
ip-rule default
next-hop PBR
exit
exit
