XT7000 Series XT5000 Series XT4000 Series Scopia
®
XT
Executive
Microphone Pod
physical
dimensions and net
weight
Diameter: 13.4cm
(5.3"), Weight: 0.45
kg (1 lb)
Diameter: 14cm
(5.5"), Weight: 0.3
kg (0.7 lb)
Diameter: 12cm
(4.7"), Weight: 0.4
kg (0.9 lb)
Includes a built-in
microphone (can
connect optional
Microphone Pod)
Microphone Pod
capabilities
Premium 3-way
Microphone Pod:
360º range
Up to 2 cascaded
pods
3-way Microphone
Pod:
360º range
Up to 2 cascaded
pods
1-way Microphone
Pod:
180º range
Optional 3-way
Microphone Pod
Optional 3-way
Microphone Pod:
360º range
Frequency response: 50 – 22,000 Hz
XT Remote Control
Unit batteries
2 x AAA batteries. Displays low battery warning on the XT Series monitors: is half-
charged; is low charge.
Table 3: Video, audio and control capabilities on page 19 lists the protocols and software
requirements.
Table 3: Video, audio and control capabilities
XT7000 Series and
XT5000 Series
Scopia
®
XT Executive XT4000 Series
Signaling protocols H.323, SIP, ISDN (requires Scopia
®
Gateway for ISDN). Each endpoint can use a
different protocol in the same meeting.
Video codecs H.265 (XT7000 Series only), H.264 High Profile SVC (point-to-point calls only), H.
264 High Profile, H.264 SVC, H.264, H.263++, H.263+, H.263
Dual video H.239 (H.323); BFCP (SIP)
HDMI input formats 1920 x 1080 at 25, 30, 50, 60fps (excluding XT4200, optional for XT5000 720)
1280 x 720 at 25, 30, 50, 60fps
720 x 576 at 50fps
720 x 480 at 60fps
640 x 480 at 60fps
Live video resolution 1920 x 1080 at 25, 30, 50, 60fps: HD1080p (excluding XT4200, optional for
XT5000 720)
1280 x 720 at 25, 30, 50, 60fps: HD 720p
1024 x 576 at 25, 30fps: w576p
768 x 448 at 25, 30fps: w448p
704 x 576 at 25, 30fps: 4CIF
704 x 480 at 25, 30fps: 4SIF
Table continues…
Technical Specifications
April 2015 Avaya Scopia
®
XT Series Deployment Guide 19
