CONNECTIONS AND SETUP
-12-
STEP 5: Set the speed dome camera at the DVR side.
Go to “ADVANCE” l “REMOTE” to set the speed dome camera.
a) Select the device to “PTZ”.
b) Set the ID to the value the same as the one set in the speed dome camera. The default ID of the
camera is 000.
c) Select the protocol to “NORMAL”.
d) Set the baud rate to the value the same as the one set in the speed dome camera. The default baud
rate of the camera is 2400.
REMOTE
TITLE DEVICE ID PROTOCOL RATE
CH1 PTZ 000 NORMAL 2400
CH2 CAMERA 000 NORMAL 2400
CH3 CAMERA 000 NORMAL 2400
CH4 CAMERA 000 NORMAL 2400
CH5 CAMERA 000 NORMAL 2400
CH6 CAMERA 000 NORMAL 2400
CH7 CAMERA 000 NORMAL 2400
CH8 CAMERA 000 NORMAL 2400
CH9 CAMERA 000 NORMAL 2400
CH10 CAMERA 000 NORMAL 2400
NEXT
PLEASE CONSULT YOUR INSTALLER FOR ADVANCE SETTING
uv SELECT s BACK t NEXT ENTER
3.3 Power Setup
This device should be operated only with the type of power source indicated on the manufacturer’s label. Connect
the indicated AC power cord to the power adapter, and plug into an electrical outlet. The power LED will be on.
Note: Before the DVR is powered on, make sure the cameras are connected and power-supplied for the
detection of the camera video system to be correct.
Note: To ensure that your DVR works constantly and properly, it's recommended to use an UPS,
Uninterruptible Power Supply (Optional), for continuously operation.
3.4 Date and Time Setting
Before operating your DVR, please set the date and time on your DVR FIRST.
Note: Please DO NOT change the date or time of your DVR after the recording function is activated.
Otherwise, the recorded data will be disordered and you will not be able to find the recorded file
to backup by time search. If users change the date or time accidentally when the recording
function is activated, it’s recommended to clear all HDD data, and start recording again.
Note: For the first time to use the DVR, please power it on for at least 48 hours continuously after the
date & time is set correctly. It helps to prevent DVR time from resetting after the disconnecting of
DVR power. If the DVR time resets after the disconnecting of DVR power, for example, caused by
a power outage, the battery might run out and please replace the battery as described in
“APPENDIX 6 DVR BATTERY REPLACEMENT” at page 58.
Press “MENU” and enter the password to go to the quick-start menu list. The default admin password is 0000.
To Next Page
