Avtech AVC798 User Manual

OVERVIEW
-2-
‧ Supports manual / timer / motion / network recording
‧ Supports TCP/IP, PPPoE, DHCP and DDNS network connection.
1.3 Specifications
1.3.1 Models with DVD Writer
MODEL Model 1 Model 2 Model 3
Video System NTSC / PAL (auto detection)
Video Compression Format H.264
Video Input
(Composite video signal 1 Vp-p 75Ω BNC)
16 Channels 8 Channels 4 Channels
Video Loop Output
(Composite video signal 1 Vp-p 75Ω BNC)
16 Channels 8 Channels 4 Channels
Main Monitor
Output
For stable display
Video Output (BNC)
Call Monitor
Output
For sequence display
Video Output (VGA)
(up to 1600 x 1200)
Built-in VGA output for LCD monitor
Audio Input 4 Channels (Mono) 4 Channels (Mono)
Audio Output 2 Channels (Mono) 1 Channel (Mono)
Multiplex Operating Supports live display, record, playback, backup, and network simultaneously
120 IPS @ 704×480 <NTSC> 60 IPS @ 704×480 <NTSC>
30 IPS @ 704×480 <NTSC>
Maximum Recording Rate (Frame)
100 IPS @ 704×576 <PAL> 50 IPS @ 704×576 <PAL>
25 IPS @ 704×576 <PAL>
240 IPS @ 720×240 <NTSC> 120 IPS @ 704×240 <NTSC> 60 IPS @ 704×240 <NTSC>
Maximum Recording Rate (Field)
200 IPS @ 720×288 <PAL> 100 IPS @ 704×288 <PAL> 50 IPS @ 704×288 <PAL>
480 IPS @ 360×240 <NTSC> 240 IPS @ 360×240 <NTSC>
120 IPS @ 352×240 <NTSC>
Maximum Recording Rate (CIF)
400 IPS @ 360×288 <PAL> 200 IPS @ 360×288 <PAL>
100 IPS @ 352×288 <PAL>
Recording Mode Manual / Timer / Motion / Alarm / Remote
Recording Quality Options Super Best, Best, High & Normal
Pre-alarm Recording YES (8 MB)
HDD Type SATA
HDD Storage
* HDDs are optional
** Supports up to 1TB per HDD
Accommodates up to two SATA HDDs Accommodates one SATA HDD
HDD Quick Cleaning --
Delete HDD Data Efficiently
(1TB within 2 seconds)
Quick Search Time / Motion / Alarm
USB Flash Drive Backup YES
DVD Writer Backup YES
Playback on PC Windows Media Player compatible
Network Transfer Format H.264
Ethernet 10/100 Base-T.
Network Protocol TCP/IP, PPPOE, DHCP and DDNS (Dynamic IP)
Network Surveillance Interface
Licensed Software “Video Viewer” / Internet Explorer & Firefox web browser / QuickTime
(20 users on-line simultaneously)
Remote Independent Operation YES
Network Alarm Notification E-mail and FTP server
CMS (Central Management System) YES (Maxmium: 16 different IP addresses)
R.E.T.R. (Remote Event Trigger
Recording)
NO YES
Operating System for Network
Function
Windows Vista / XP / 2000; Apple Mac
IR Remote Control YES
Multilingual OSD YES
Motion Detection Area 16 × 12 grids per channel
Motion Detection Sensitivity 4 adjustable parameters for accurate detection
PTZ Control Pelco-D / Pelco-P / our own protocol
External Alarm 16 inputs, 1 output 8 inputs, 1 output 4 inputs, 1 output
Picture Zoom 2X digital zoom (live & playback)
Key Lock (Password Protection) YES
Video Loss Detection YES
Camera Title Supports up to 6 letters
Video Adjustable Hue / Color / Contrast / Brightness
Date Display Format YY/MM/DD, DD/MM/YY, MM/DD/YY
Daylight Saving YES
Power Source (±10%) DC 19V
