FRONT AND REAR PANELS
-5-
2. FRONT AND REAR PANELS
2.1 Front Panel
1) LED Indicators
HDD is reading or recording.
DVR is powered on.
An alarm is triggered.
Timer recording is on.
Under playback status (For 4CH model only).
HDD is full (For 16CH / 8CH models only).
2) MENU
Press “MENU” to enter the main menu.
3) ENTER
Press “ENTER” to confirm the setting.
4) SLOW
Under the playback mode, press “SLOW“ to show slow playback.
5) ZOOM
Press “ZOOM” to enlarge the picture of selected channel in the FRAME or FIELD recording mode.
6)
Press “ “ to show the 4 channel display mode.
7) SEQ
Press “SEQ” to activate the call monitor function and press “SEQ” again to escape the call monitor mode.
8) POWER
Press to turn on / off the DVR.
(Under the recording mode, please stop recording before turning off the DVR).
9) CH1 ~ 16 / CH1 ~ 8 / CH1 ~ 4
Press the channel number buttons to select the channel to display.
10) PLAY
Press to playback the recorded data.
11) ▲ (PAUSE/+) / ▼ (STOP/-) / ◄ (REW) / ► (FF)
Press ▲ / ▼ / ◄ / ► to move the cursor up / down / left / right.
Under the playback mode, press “ PAUSE” to pause playback.
Under the playback mode, press “ STOP” to stop playback.
Under the playback mode, press “FF“ to fast forward.
Under the playback mode, press “REW“ to fast rewind.
