Avtech AVC798 User Manual

OVERVIEW
-3-
MODEL Model 1 Model 2 Model 3
Power Consumption ＜64 W < 42 W
Operating Temperature 0℃ ~ 40℃ (32℉~104℉) 10℃ ~ 40℃ (50℉~104℉)
Dimensions (mm)** 432(W) × 90(H) × 326(D) 375(W) × 61(H) × 281(D)
System Recovery System auto recovery after power failure
Optional Peripherals Keyboard controller
* The specifications are subject to change without notice.
1.3.2 Models without DVD Writer
MODEL Model 4 Model 5 Model 6 Model 7 Model 8
Video System NTSC / PAL (auto detection)
Video Compression Format H.264
Video Input
(Composite video signal 1 Vp-p 75Ω BNC)
16 Channels 8 Channels 4 Channels
Video Loop Output
(Composite video signal 1 Vp-p 75Ω BNC)
16 Channels -- 8 Channels -- 4 Channels
Main Monitor
Output
For stable display
Video Output (BNC)
Call Monitor
Output
For sequence
display
--
For sequence
display
--
For sequence
display
Video Output (VGA)
(up to 1600 x 1200)
Built-in VGA
output for LCD
monitor
--
Built-in VGA
output for LCD
monitor
--
Built-in VGA
output for LCD
monitor
Audio Input
4 Channels
(Mono)
1 Channel (Mono)
4 Channels
(Mono)
1 Channel (Mono)
4 Channels
(Mono)
Audio Output
2 Channels
(Mono)
1 Channel (Mono)
2 Channels
(Mono)
1 Channel (Mono) 1 Channel (Mono)
Multiplex Operating Supports live display, record, playback, backup, and network simultaneously
120 IPS @ 704×480 <NTSC> 60 IPS @ 704×480 <NTSC>
30 IPS @
704×480 <NTSC>
Maximum Recording Rate (Frame)
100 IPS @ 704×576 <PAL> 50 IPS @ 704×576 <PAL>
25 IPS @
704×576 <PAL>
240 IPS @
720×240 <NTSC>
--
120 IPS @
704×240 <NTSC>
--
60 IPS @
704×240 <NTSC>
Maximum Recording Rate (Field)
200 IPS @
720×288 <PAL>
--
100 IPS @
704×288 <PAL>
--
50 IPS @
704×288 <PAL>
480 IPS @ 360×240 <NTSC> 240 IPS @ 360×240 <NTSC>
120 IPS @
352×240 <NTSC>
Maximum Recording Rate (CIF)
400 IPS @ 360×288 <PAL> 200 IPS @ 360×288 <PAL>
100 IPS @
352×288 <PAL>
Recording Mode
Manual / Timer /
Motion / Alarm /
Remote
Manual / Timer /
Motion / Remote
Manual / Timer /
Motion / Alarm /
Remote
Manual / Timer /
Motion / Remote
Manual / Timer /
Motion / Alarm /
Remote
Recording Quality Options Super Best, Best, High & Normal
Pre-alarm Recording YES (8 MB)
HDD Type SATA
HDD Storage
* HDDs are optional
** Supports up to 1TB per HDD
Accommodates up to two SATA HDDs
HDD Quick Cleaning --
Delete HDD Data
Efficiently (1TB
within 2 seconds)
Quick Search
Time / Motion /
Alarm
Time / Motion
Time / Motion /
Alarm
Time / Motion
Time / Motion /
Alarm
USB Flash Drive Backup YES
DVD Writer Backup
Available for self
installation
--
Available for self
installation
--
Playback on PC Windows Media Player compatible
Network Transfer Format H.264
Ethernet 10/100 Base-T.
Network Protocol TCP/IP, PPPOE, DHCP and DDNS (Dynamic IP)
Network Surveillance Interface
Licensed Software “Video Viewer” / Internet Explorer & Firefox web browser / QuickTime
(20 users on-line simultaneously)
Remote Independent Operation YES
Network Alarm Notification
E-mail and FTP
server
--
E-mail and FTP
server
--
E-mail and FTP
server
CMS (Central Management System) YES (Maxmium: 16 different IP addresses)
R.E.T.R. (Remote Event Trigger
Recording)
NO YES
Operating System for Network
Function
Windows Vista / XP / 2000; Apple Mac
IR Remote Control YES
Multilingual OSD YES

Avtech AVC798 Specifications

General

Brand	Avtech
Model	AVC798
Category	DVR
Language	English
